PSU 1300W 80 GOLD GIGABYTE PG5 1300W Single 12V Rail 140mm Cooling Fan Intel ATX 12V Version 3.0 1 x PCIe 5.0 16-Pin Connector 8 x PCIe 6 2-Pin Connectors 12 x SATA Connectors Modular Cable Design 80 Plus Gold Efficiency Rating Yellow Tipped 16-Pin Connector Fluid Dynamic Bearing Fan Key Specs Total Connectors 1x 20 4-Pin ATX Motherboard 2x 4 4-Pin EPS CPU 1x 16-Pin PCIe (12VHPWR) 8x 6 2-Pin PCIe 12x 15-Pin SATA 6x 4-Pin Peripheral / Molex 2x 4-Pin Floppy Show Less Cable Design Modular Total Wattage 1300 W Number of 12 V Rails 1 Efficiency Rating 80 PLUS Gold Form Factor ATX Connectivity Total Connectors 1x 20 4-Pin ATX Motherboard 2x 4 4-Pin EPS CPU 1x 16-Pin PCIe (12VHPWR) 8x 6 2-Pin PCIe 12x 15-Pin SATA 6x 4-Pin Peripheral / Molex 2x 4-Pin Floppy Cable Design Modular PCIe Connector Distances 27.6″ / 700 mm SATA Connector Distances 25.6″ / 650 mm 5.9″ / 150 mm 5.9″ / 150 mm 5.9″ / 150 mm Peripheral Connector Distances 23.6″ / 600 mm 5.9″ / 150 mm 5.9″ / 150 mm 5.9″ / 150 mm ATX Connector Distance 24″ / 610 mm EPS Connector Distances 25.6″ / 650 mm Electrical Total Wattage 1300 W Number of 12 V Rails 1 Combined Power for 12 V 1300 W Max Load for 12 V 108.3 A Combined Power for 3.3/ 5 V 125 W Max Load for 3.3 V 25 A Max Load for 5 V 25 A Max Power for 5 Vsb 17.5 W Max Load for 5 Vsb 3.5 A Max Power for -12 V 3.6 W Max Load for -12 V 0.3 A Peak Power 1300 W AC Input Power 100 to 240 VAC, 50 / 60 Hz General Efficiency Rating 80 PLUS Gold Active Power Factor Correction No Efficiency 87% at 100% Load 90% at 50% Load 87% at 20% Load Cooling Fan Size 140 mm Bearing Type Ball Physical Form Factor ATX Compliance ATX 12 V v3.0 Protection Over-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Under-Voltage Protection Dimensions 5.9 x 3.4 x 6.3″ / 150 x 86 x 160 mm Kategori: Komponente PC, Power Supply
